Servo Extension Cable And RC Harness Builds
Compact signal and power harnesses for RC aircraft, robotics, camera gimbals, FPV payloads, and prototype electronics.
We build custom lengths, gauges, pinouts, and connector combinations across JST PH, XH, GH, ZH, SH, EH, VH, Molex PicoBlade, Harwin M20 DuPont-style connectors, and standard servo leads. Cross-connect flight controllers, receivers, payload boards, and actuators without hand-crimping every prototype cable.
Why MiniProto
Professional Harnesses Without The Wait
Small Connector Experience
JST, PicoBlade, Harwin M20, and servo-style leads need careful crimping, pin checks, and strain relief. We build them repeatedly.
Custom Lengths And Gauges
Specify short board-to-board jumpers, long servo extensions, branch harnesses, or mixed signal and power cable sets.
Drone And Robotics Ready
Pair these signal harnesses with our drone power and Pixhawk wiring solution pages for a complete UAV wiring package.
Technical Specifications
Compact Connector Options
Common RC, robotics, and electronics connector families used for servo extension cable projects.
| Connector | Pitch | Gauge | Typical Use |
|---|---|---|---|
| JST PH | 2.0 mm | 24 to 28 AWG | Battery taps and compact boards |
| JST XH | 2.5 mm | 22 to 28 AWG | Balance leads and board wiring |
| JST GH | 1.25 mm | 26 to 30 AWG | Flight controllers and sensors |
| JST SH/ZH | 1.0 to 1.5 mm | 28 to 32 AWG | Micro electronics and FPV |
| Molex PicoBlade | 1.25 mm | 26 to 30 AWG | Camera and payload boards |
| Harwin M20 | 2.54 mm | 22 to 28 AWG | DuPont-style development wiring |
| Servo Leads | 0.1 inch | 22 to 26 AWG | RC receivers, servos, gimbals |
We verify pin orientation because small connector families often flip wire order between mating halves.
RC And FPV Wiring
- Servo extension cables in custom lengths
- Flight controller and receiver adapters
- Camera, VTX, and payload wiring for FPV builds
Robotics And Gimbals
- Compact board-to-board signal leads
- Camera gimbal and actuator harnesses
- Mixed JST, PicoBlade, Harwin, and servo connector sets
Popular Preconfigured Builds
Start From A Reviewed Configuration
Use these catalog builds as a starting point, or send a drawing when the assembly needs connector, pinout, or routing review.
Custom JST PH to JST PH Wire Harness Assembly
Configure For Price
Custom JST XH to Harwin DuPont (M20) Wire Harness Assembly
Configure For Price
Custom JST GH to Molex Micro-Fit Wire Harness Assembly
Configure For Price
Custom JST SH to JST GH Wire Harness Assembly
Configure For Price
Custom Molex PicoBlade to JST GH Wire Harness Assembly
Configure For Price
Applications
Built Around Real Installations
RC aircraft and ground vehicles
Robotics sensors and actuators
Camera gimbals and payloads
FPV drones and electronics prototypes
Process
From Requirements To Tested Harnesses
Choose Connectors
Send connector families, pin count, wire colors, gauge, and orientation notes.
Confirm Pinout
We check mating direction, reversed pin order risk, length, branch points, and labels.
Build Small Leads
Cables are crimped, inspected, continuity checked, and packed by harness type.
Related Links
More Servo And RC Harnesses Resources
Explore related connector, service, and industry pages before you configure or quote a build.
Stop Hand-Crimping Every Servo Lead
Start with a compact preconfigured build or upload a pinout for a custom RC harness quote.
