Custom JST VH to Generic DIN Ferrule Wire Harness Assembly
Custom JST VH to Generic DIN Ferrule Wire Harness Assembly, assembled in the USA with a quick two-week lead time. Fully customizable pin count, length, and gender. Reliable, durable, and precision-crafted!
| Pin counts stocked | 1, 2, 3 |
|---|---|
| Housing MPNs | VHR-2N, VHR-3N, 121010150, 121210100, 12510025, 12510034, 12610050, 12710025, 12710034, 12710150, 12810050, 12810150, 121010075, 121010100, 121210075, 12610100, 12710100, 12810100, 121210400, 1076980000, 1076990000, 9019030000, 1181010, 1181050, 1181075, 121010250, 121010400, 121010600, 121210150, 121210250, 121210600, 121510150, 121510250, 121810150, 121810250, 122010150, 122010250, 122010400, 12710250, 12910400, 565600000, F75-10-M, 11101050, 11101075, 1161075, 1181015, 121510400, 121510600, 121810400, 121810600, 2202.0, 9019040000, 9019050000, F75-6-M, F75-8-M, 2397.0, 2398.0, 3127.0, 9019060000, 11121075, 2620.0, 11101010, 11121010, 1161010, 1181025, 1181208, 2621.0, 3080.0, 11181015, 11121025, 11610025, 1161014, 1161034, 11810025, 1181014, 1181034, 2-966067-3, 565700000, FSD75-6-D, 1-966066-5, 11101015, 11101040, 11121015, 11121040, 1161015, 11181025, 9019220000, 1200164, 11181040, 216-246, F82-20-M, 9018520000, 9018510000, 1381010, 1381050, 9037390000, 9037470000, 9037480000, 13101010, 13101075, 1381075, 9037500000, 966144-3, 9037510000, 9037560000, 216-542, 9037550000, 9037530000, 9037540000, 9037520000, FTD75-8-D, 13141060 |
| Crimp / seal | Unsealed 3.96 mm JST VH: SVH-21T-P1.1 / SVH-21GH-P1.1 (18–22 AWG) or SVH-41T-P1.1 (16–20 AWG) sockets in VHR housings, 10 A / 250 V. No cavity seals. DIN ferrules are bootlace end-terminations on the pigtail, not cavity seals for the VH housing. Pair gauge is the overlapping 16–22 AWG band. |
| Gauge range | 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26 AWG, 28 AWG, 30 AWG, 32 AWG |
| Length range | 100–5000 mm |
| Lead time | 20–40 business days |
{
