Custom JST VH to Amass XT60 Wire Harness Assembly
Assembled in the USA with a two-week base lead time, this harness is fully customizable in pin count, length, and gender. Perfect for EV systems, drones, and high-power battery packs, it combines JST VH’s current-handling capability with the Amass XT60’s durable, low-resistance design for efficient power transfer. Fun fact: The XT60 is widely used in high-performance applications for its exceptional reliability under heavy loads. Order now for a custom, high-quality solution!
| Pin counts stocked | 2, 3 |
|---|---|
| Housing MPNs | VHR-2N; VHR-3N; XT60, F/Rec; XT60, M/Plug; XT60E, F/Rec; XT60, F/Rec w/Protector; XT60, M/Plug w/Protector |
| Crimp / seal | Unsealed 3.96 mm JST VH: SVH-21T-P1.1 / SVH-21GH-P1.1 (18–22 AWG) or SVH-41T-P1.1 (16–20 AWG) sockets in VHR housings, 10 A / 250 V. No cavity seals. XT60 uses solder cups, not crimps; XT60H back cover organizes the solder-joint area but does not seal the gold-and-yellow two-pole interface. Pair gauge is the VH 16–22 AWG band; pair current is the 10 A VH contact, not the XT60 catalog rating. |
| Gauge range | 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26 AWG, 28 AWG, 30 AWG, 32 AWG |
| Length range | 100–5000 mm |
| Lead time | 20–40 business days |
{
"connectors": [
{
"ref": {
"mpn": "VHR-2N"
},
"side": "left"
},
{
"ref": {
"mpn": "XT60, F/Rec"
},
"side": "right"
}
],
"wires": [
{
"sourceConnector": 0,
"sourcePin": 1,
"targetConnector": 1,
"targetPin": 1,
"gauge": "18 AWG",
"color": "red",
"wireFamily": "GXL",
"lengthMm": 150
},
{
"sourceConnector": 0,
"sourcePin": 2,
"targetConnector": 1,
"targetPin": 2,
"gauge": "18 AWG",
"color": "red",
"wireFamily": "GXL",
"lengthMm": 150
}
]
}
