Custom JST PH to JST PH Wire Harness Assembly
Our Custom JST PH to JST PH wire harness assembly provides a reliable, low-power connection in a compact design. Perfect for consumer electronics, robotics, and small devices, each harness is tailored to your specifications, including wire length, gauge, and connector configurations. Built for a secure fit and ready to ship in 2-3 days, this assembly ensures fast, seamless integration into your project.
| Pin counts stocked | 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16 |
|---|---|
| Housing MPNs | PHR-2, PHR-3, PHR-4, PHR-5, PHR-6, PHR-7, PHR-8, PHR-9, PHR-10, PHR-11, PHR-12, PHR-13, PHR-14, PHR-15, PHR-16 |
| Crimp / seal | Unsealed 2.0 mm JST PH: SPH-002T-P0.5S / SPH-002T-P0.5L socket contacts in PHR housings, 24–28 AWG, 2 A / 100 V. No cavity seals. |
| Gauge range | 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26 AWG, 28 AWG, 30 AWG, 32 AWG |
| Length range | 100–5000 mm |
| Lead time | 20–40 business days |
{
