Custom Amass XT90 to Generic DIN Ferrule Wire Harness Assembly
Custom Amass XT90 to Generic DIN Ferrule Wire Harness Assembly, proudly assembled in the USA with a fast 2-3 day lead time. Fully customizable pin count, length, and gender. Built for reliability and durability!
| Pin counts stocked | 1, 2 |
|---|---|
| Housing MPNs | XT90, F/Rec; XT90, M/Plug; 121010150; 121210100; 12510025; 12510034; 12610050; 12710025; 12710034; 12710150; 12810050; 12810150; 121010075; 121010100; 121210075; 12610100; 12710100; 12810100; 121210400; 1076980000; 1076990000; 9019030000; 1181010; 1181050; 1181075; 121010250; 121010400; 121010600; 121210150; 121210250; 121210600; 121510150; 121510250; 121810150; 121810250; 122010150; 122010250; 122010400; 12710250; 12910400; 565600000; F75-10-M; 11101050; 11101075; 1161075; 1181015; 121510400; 121510600; 121810400; 121810600; 2202.0; 9019040000; 9019050000; F75-6-M; F75-8-M; 2397.0; 2398.0; 3127.0; 9019060000; 11121075; 2620.0; 11101010; 11121010; 1161010; 1181025; 1181208; 2621.0; 3080.0; 11181015; 11121025; 11610025; 1161014; 1161034; 11810025; 1181014; 1181034; 2-966067-3; 565700000; FSD75-6-D; 1-966066-5; 11101015; 11101040; 11121015; 11121040; 1161015; 11181025; 9019220000; 1200164; 11181040; 216-246; F82-20-M; 9018520000; 9018510000; 1381010; 1381050; 9037390000; 9037470000; 9037480000; 13101010; 13101075; 1381075; 9037500000; 966144-3; 9037510000; 9037560000; 216-542; 9037550000; 9037530000; 9037540000; 9037520000; FTD75-8-D; 13141060 |
| Crimp / seal | XT90 uses solder cups, not crimps; XT90H back cover organizes the solder-joint area but does not convert the gold-and-yellow two-pole interface into a sealed system. Current Amass catalog lists 45 A max for XT90H and XT90S-F with 10 AWG. DIN ferrules are bootlace end-terminations on the pigtail, not cavity seals for the XT shell. |
| Gauge range | 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26 AWG, 28 AWG, 30 AWG, 32 AWG |
| Length range | 100–5000 mm |
| Lead time | 20–40 business days |
{
