Custom Amass XT60 to TE Deutsch DT Wire Harness Assembly
The Custom Amass XT60 to TE Deutsch DT wire harness assembly ensures reliable, high-power connections in rugged environments like automotive and industrial systems. Fully customizable for wire gauge, length, and terminations, and ships within two weeks.
| Pin counts stocked | 2, 3, 4, 6, 8, 12 |
|---|---|
| Housing MPNs | XT60, F/Rec; XT60, M/Plug; XT60, F/Rec w/Protector; XT60, M/Plug w/Protector; DT04-2P; DT04-2P-C015; DT06-2S; DT06-2S-C015; DT04-3P; DT04-3P-C015; DT06-3S; DT06-3S-C015; DT04-4P; DT04-4P-C015; DT06-4S; DT06-4S-C015; DT04-6P; DT04-6P-C015; DT06-6S; DT06-6S-C015; DT06-08SB-C015; DT04-08PB-C015; DT04-08PA; DT04-08PA-C015; DT04-08PC-C015; DT06-08SC-C015; DT04-08PC; DT06-08SA; DT06-08SA-C015; DT06-08SB; DT06-08SC; DT04-08PD; DT04-08PB; DT06-08SD; DT04-12PA; DT04-12PA-C015; DT04-12PB; DT04-12PB-C015; DT04-12PC; DT04-12PC-C015; DT06-12SA; DT06-12SA-C015; DT06-12SB; DT06-12SB-C015; DT06-12SC; DT06-12SC-C015; DT06-12SD; DT04-12PD; DT04-12PD-C015 |
| Crimp / seal | XT60 uses solder cups, not crimps; XT60H back cover organizes the solder-joint area but does not seal the gold-and-yellow two-pole interface. Deutsch DT size-16 contacts 0460-202-16141 pin / 1062-16-0122 socket, required W-series wedgelocks, N-seal or E-seal rear seals; unused cavities need sealing plugs. |
| Gauge range | 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26 AWG, 28 AWG, 30 AWG, 32 AWG |
| Length range | 100–5000 mm |
| Lead time | 20–40 business days |
{
"connectors": [
{
"ref": {
"mpn": "XT60, F/Rec"
},
"side": "left"
},
{
"ref": {
"mpn": "DT04-2P"
},
"side": "right"
}
],
"wires": [
{
"sourceConnector": 0,
"sourcePin": 1,
"targetConnector": 1,
"targetPin": 1,
"gauge": "18 AWG",
"color": "red",
"wireFamily": "GXL",
"lengthMm": 150
},
{
"sourceConnector": 0,
"sourcePin": 2,
"targetConnector": 1,
"targetPin": 2,
"gauge": "18 AWG",
"color": "red",
"wireFamily": "GXL",
"lengthMm": 150
}
]
}
